Feature

Physical Port

• One 10/100/1000BASE-T with IEEE 802.3at PoE+ Gigabit RJ45 port
  • Data + Power output
• One 1000BASE-X SFP  interface
  • Data input
• One 2-pin terminal block for power input. (Power Range: 24 ~ 56V DC)

Power over Ethernet

• 1-port data + power output
  • Complies with IEEE 802.3at Power over Ethernet plus PSE
  • Compatible with IEEE 802.3at/802.3af powered devices
  • Supports total PoE budget up to 30 watts for PoE output port
  • Provides DC 55V power over RJ45 Ethernet cable to device with Ethernet port
  • Auto detects IEEE 802.3at/af equipment and protects devices from being damaged by incorrect installation
  • Remote power feeding up to 100m
  • Auto detects powered device (PD)

Industrial Case and Installation

• IP67-rated and IK-10 rated aluminum case
• Wall-mount design
• Supports 6KV DC Ethernet ESD protection
• -40 to 75 degrees C operating temperature
• Plug and Play installation
